2007 Honda Accord Alternator Upgrade — 3.0L V6

The 2004-2007 Honda Accord 3.0L V6 carries roughly 130-150 amps from the factory. The V6 has more headroom than the four-cylinder Accord, but a serious audio system still takes it to the limit. This direct-fit JS Alternators unit replaces the stock alternator with 250-320 amps in the same location, using the same mounting and the factory plug, with full Honda ELD compatibility retained.

Fits these model years

  • 2004, 2005, 2006 and 2007 Honda Accord 3.0L V6

V6 Accord charging headroom

Factory load on a loaded Accord V6 runs well over 100 amps before you add anything. Put a 1,000-watt RMS system on top of that and the stock alternator spends most of its life at or beyond rated output, especially at idle where it spins slowest. Voltage sag at idle with the air conditioning on is the usual first symptom. See our Honda Accord alternator guide and the alternator sizing guide for how to size the upgrade.

Fitment:

This is a direct fit high-output alternator for the 2004-2007 Honda Accord 3.0L. Being a direct fit, this alternator fits directly into your stock alternator location.

Plug:

This high-output alternator comes with a factory style plug so that your OEM plug will plug directly into the alternator. Therefore, with an OEM style regulator, it will have a factory voltage set point.

NOTE: If you require charging at a certain voltage setpoint, we offer a selection of different voltage regulators that you will need to purchase with the alternator for it to be installed. View our Regulator Options Here.

Pulley:

This alternator comes with a smaller pulley, which causes it to spin faster than a larger pulley and helps the alternator produce its maximum output. With a smaller pulley it is required to install a belt 1/2 inch to 1 inch shorter than stock. See this blog article for assistance in finding the correct shorter belt.

Big 3 Wiring:

When upgrading to a high-output alternator, it is required to upgrade your wiring with the Big 3 Wiring Upgrade Kit. It is recommended to use 1/0 100% copper wires for the upgrade. Our Big 3 Wiring Upgrade Kit is 10% off with a purchase of a JS Alternator; use code BIG3DISCOUNT at checkout.

Learn why the Big 3 Wiring Upgrade Kit is required for all high output alternators

2004-2007 Honda Accord V6 3.0L High Output Alternator

$399.00 $499.00

Key Features

  • Direct-fit for 2004-2007 Honda Accord V6 3.0L
  • Available in 250A and 320A
  • Factory-style plug with no rewiring
  • Factory voltage set point
  • Smaller pulley for maximum output
  • Requires 1/2" to 1" shorter belt
  • Big 3 wiring upgrade required (10% off)
  • 1 Year Warranty
  • Built in Anderson, SC
Amperage

Financing available at checkout

Shop Pay Affirm Snap Finance Pay Pal
USA-Made
1-Year Warranty
Bench Tested
Free ShippingLower 48 States
4.81 Stars

2007 Honda Accord Alternator Upgrade — 3.0L V6

The 2004-2007 Honda Accord 3.0L V6 carries roughly 130-150 amps from the factory. The V6 has more headroom than the four-cylinder Accord, but a serious audio system still takes it to the limit. This direct-fit JS Alternators unit replaces the stock alternator with 250-320 amps in the same location, using the same mounting and the factory plug, with full Honda ELD compatibility retained.

Fits these model years

  • 2004, 2005, 2006 and 2007 Honda Accord 3.0L V6

V6 Accord charging headroom

Factory load on a loaded Accord V6 runs well over 100 amps before you add anything. Put a 1,000-watt RMS system on top of that and the stock alternator spends most of its life at or beyond rated output, especially at idle where it spins slowest. Voltage sag at idle with the air conditioning on is the usual first symptom. See our Honda Accord alternator guide and the alternator sizing guide for how to size the upgrade.

Fitment:

This is a direct fit high-output alternator for the 2004-2007 Honda Accord 3.0L. Being a direct fit, this alternator fits directly into your stock alternator location.

Plug:

This high-output alternator comes with a factory style plug so that your OEM plug will plug directly into the alternator. Therefore, with an OEM style regulator, it will have a factory voltage set point.

NOTE: If you require charging at a certain voltage setpoint, we offer a selection of different voltage regulators that you will need to purchase with the alternator for it to be installed. View our Regulator Options Here.

Pulley:

This alternator comes with a smaller pulley, which causes it to spin faster than a larger pulley and helps the alternator produce its maximum output. With a smaller pulley it is required to install a belt 1/2 inch to 1 inch shorter than stock. See this blog article for assistance in finding the correct shorter belt.

Big 3 Wiring:

When upgrading to a high-output alternator, it is required to upgrade your wiring with the Big 3 Wiring Upgrade Kit. It is recommended to use 1/0 100% copper wires for the upgrade. Our Big 3 Wiring Upgrade Kit is 10% off with a purchase of a JS Alternator; use code BIG3DISCOUNT at checkout.

Learn why the Big 3 Wiring Upgrade Kit is required for all high output alternators

Shipping is free to the lower 48 states and Washington, D.C. Orders to Alaska and Hawaii are charged a shipping rate, shown at checkout. Orders ship in approximately 3–5 business days, sometimes sooner. Many ship within 1–2 business days. Alternators that require a custom bracket can take 5–8 business days. If for some reason parts are on back order, we will notify you, but this is not common. If an order is placed after 12pm EST, shipping timeframes begin the next business day.



REQUIRED Installation Steps:

(Wear eye protection, remove jewelry/loose items, and allow car to fully cool before starting installation)



  • Batteries must be fully charged before installation.
  • Make sure vehicle is off and engine is cool.
  • Disconnect the negative cable from the battery/batteries.
  • Disconnect all other wiring from the alternator.
  • Remove the belt (note the belt routing before removing).
  • Remove the bracket bolts and original alternator.
  • Mount the new alternator. Typically the original bolts will be used.
  • The belt must be replaced with a .5 to 1-inch shorter belt when installing a high output alternator, unless otherwise specified.
  • Install the new belt. Make sure the routing is correct and the belt is aligned with all pulley grooves.

Connections Of Frame/Body: Clean all metal surface of any paint or rust with a wire brush or die grinder. Use a conductive corrosion inhibitor available at any electrical parts supply store.

Grounding (Uni-body frame warning): Many newer vehicles have “uni-body” or sheet metal frame structures with no traditional “full frame”. Because of seams and adhesive attached body components, additional steps may be required for proper chassis grounding. Choose the location on the sub-frame with the thickest metal possible. If there is lower than spec charging voltage at the battery, move ground connections or add additional ground cables to different frame components.

*** WARNING *** Keep all electrical wiring at least 12” away from heat sources to avoid fire of the cable jacket!

There are THREE Regulator styles. Read each to determine which one your alternator has and read its the included notes:

  1. Factory Plug: The factory harness can be plugged into the new regulator. Be sure factory plug is clear of all debris and fully snapped into place in regulator.
  2. Turn On Single Wire Alternators: Follow this step ONLY if we shipped a pigtail plug with your alternator. Connect the excite wire (L) to a 7v to 15v ignition power source and connect the sense wire (S) directly to positive post on alternator. See picture of the Pigtail Plug below. PIGTAIL PLUG:

1987-1990 Jeep Comanche 4.0L High Output Alternator

  1. Self Excite Alternators: Self-exciting or better known as “one wire” alternators will have NO plug on the alternator, and the OEM alternator harness plug will be left disconnected. This type of alternator requires only the positive and negative battery cables to be connected to the alternator to function. These alternators are internally regulated and will turn themselves on and off with engines rotation and regulate their own charging voltage. (This may cause battery light to come on).

Gauges

It is highly recommended you add a dash mounted volt gauge.

  • Connect the battery ground and confirm all other electrical connections are complete.
  • Confirm the belt path is correct and clear of obstacles.
  • Before starting the vehicle confirm that the battery is charged, as starting the vehicle with a discharged battery can damage the alternator.
  • Use a battery charger to charge the battery first if voltage is inadequate.

Ground Path Resistance Test

If resistance is greater than 0.1V confirm the following:

  • Confirm that all paint, anodizing, or rust is removed, and the connections are to bare metal.
  • Make certain all terminals are tight to the wire.
  • Make certain the ground wire is of proper size.

Charge Path Resistance Test

If resistance is greater than 0.1V confirm the following:

  • Make sure alternator charge post nut is tight.
  • Make sure charge wire is proper size.

Battery Recommendation

  • 2000 watts: upgrade main battery, 1 rear battery
  • 3500 watts: upgrade main battery, 1-2 rear batteries
  • 5000 watts: upgrade main battery, 2-3 rear batteries
  • 7500 watts: upgrade main battery, 3-4 rear batteries – 2 alternators
  • 10,000 watts: upgrade main battery, 3-5 rear batteries – 2 alternators



js alternators big 3 wiring upgrade kit installation instructions



Big 3 Wiring

  • The big 3 Wiring upgrade is an ADDITION to your factory wiring.
  • All factory connections need to remain connected.
  • For protection it is recommended to add an in line fuse to the positive wire.
  • All grounds must be cleaned to bare metal and properly secured.

All factory connections need to remain connected.
For protection it is recommended to add an in line fuse to the positive wire. All grounds must be cleaned to bare metal and properly secured.

Positive 1/0 100% Pure Copper Cable

Connect from the positive stud on the alternator to the positive on the battery

Ground 1/0 100% Pure Copper Cable

Connect from alternator mount bolt to frame/chassis

Ground 1/0 100% Pure Copper Cable

Connect from negative on battery to the frame/chassis

Big 3 Wiring Kit With RVC

  • The big 3 Wiring upgrade is an ADDITION to your factory wiring.
  • All factory connections need to remain connected.
  • For protection it is recommended to add an in line fuse to the positive wire.
  • All grounds must be cleaned to bare metal and properly secured.

All factory connections need to remain connected.
For protection it is recommended to add an in line fuse to the positive wire.
All grounds must be cleaned to bare metal and properly secured.
RVC vehicles have a GROUND SENSOR LOOP in which the ground wire will need to be ran through this loop for proper performance.

Positive 1/0 100% Pure Copper Cable

Connect from the positive stud on the alternator to the positive on the battery

Ground 1/0 100% Pure Copper Cable

Connect from alternator mount bolt through the GROUND SENSOR LOOP to the negative on the battery

Ground 1/0 100% Pure Copper Cable

Connect from negative on battery to the frame/chassis

Depending on the application you may need to run a distribution block for better connections (if you have too many upgraded wires that cannot connect directly to the battery terminals).
UNI-BODY FRAMES: Additional steps may be required for proper grounding, You may need to choose a location on the sub-frame with the thickest metal for grounding.
